Pretty Plots in MATLAB

Using MATLAB to crank through some calculations, but having trouble making the plots pretty? Here's an example that should make a nice looking plot that's ready to be inserted into a report.

figure
set(gca,'fontsize',14)
set(gcf, 'PaperSize', [8. 6.],'PaperPositionMode', 'auto');
plot(X,Y,'k^','markersize',10,'markerfacecolor','auto')
legend('mylegend','location','northeast');
xlabel('myxlabel','Interpreter','latex','fontsize',16);
ylabel('myylabel','Interpreter','latex','fontsize',16)
AXIS([xmin xmax ymin ymax])
print('-r600','-dpdf',['filename','.pdf'])

Alright, a quick rundown.

1. The 'figure' command is letting MATLAB know that we're making a picture with all the following attributes.
2. The 'set gca' command is setting the axes, which have the default handle 'gca', to have a font size of 14 here. This will control the size of the numbering on the axes, as well as the size of the font in the legend.
3. The 'set gcf' command is setting the paper size to 8" by 6", a size I find works well with the default figure output of MATLAB. This will prevent you from having to crop the plot later in a third-party photo editor.
4. The 'plot' command lists the X and Y arrays youd like to plot, 'k^' plots black upward facing triangles in a 'marker size' of 10pt, and automatically filled.
The 'legend' command puts in your legend, one entry per pair of vectors being plotted, in the northwest position.
5. The 'xlabel' and 'ylabel' commands are pretty straightforward, but the interpretter command displays the labels in the default LaTeX font instead of the MATLAB font. You can use the '$$' pairing to put in maths.
6. The 'axis' command sets the range for x and y, just comment this out if you like what MATLAB does.
7. The 'print' command will save your figure as .pdf with the filename you specify in the current directory (where your .m file is). Here, you can always specficy a path if you'd like to save figures in a different folder.

Still to come, using str2num and num2str to automatically number plots that are part of a for loop, or to name output graphs based on input data.

MATLAB: Don't ', transpose(it)

Doing a little homework for ME 7040, I discovered that there is more to transposing a matrix than just rows becoming columns and vice versa. I was doing a simple stress, strain, displacement analysis of a beam under static load. The code snippet in question is when the elemental stiffness matrix needed to be calculated by:

k = int(int(B'*D*B,r,-0.5,0.5),s,-0.5,0.5)

B is a 3xn matrix of shape functions and D a 3x3 relationship of Modulus of Elasticity and Poisson's ratio. There is obviously more to this code, including the calculations of stress and strain and the writing of an output file.

Running the code using the prime ('), the code took 143.106 seconds to run. I was initally confused by how long it took because the matrices were not that large. I then heard about the function transpose() and decided to use that. In code form:

k = int(int(transpose(B)*D*B,r,-0.5,0.5),s,-0.5,0.5)

This took only 19.735 seconds to run. So digging a little further, the operator ', also checks for complex conjugates of the matrix as well.

In conclusion, if you know that you are not dealing with complex numbers, you may want to use the transpose function and not its operator.

Tip: To time the running time of your code, put tic on the top line and toc on the last line.

SCP + SSH: Copying files from Windows to Linux

At the university I attend, it is mostly all about Windows and there is no support for linux so many things have to be done by the user to get anything done. However, most linux users are used to trying this on your own. Here I will show you how to successfully transfer files from your linux box at home to a windows computer at work/school. Linux commands refer to Ubuntu. Please see your distro's guide on installing packages.

Software Required:

Windows: Cygwin

Linux: openssh

Configuring linux box:

To install openssh, in terminal type

sudo apt-get install openssh-server

If the linux box is behind a router, please open the port corresponding to ssh. Default is 22. For more information please visit portforward.com.

To test the installation of ssh type:

ssh localhost

If everything works, then that should be up for setting up the linux box.

Configuring Windows:

After downloading setup.exe from the link above, double click to run. The important part of the installation is "Selecting Packages" diaglog box.

Expand the Net tree by pressing the +. Scroll down and look for openssh and click on "Skip" to change it to "Install". You will notice a check box under column B. Click Next when finished and complete the installation.

Operating the Windows Box:

After installation, open cygwin and a terminal will appear. The syntax for scp is:

scp [options] [[user@]host1:]filename1 ... [[user@]host2:]filename2

To copy 'report.pdf' from your Fall 2008 folder on your home directory, you would type:

scp report.pdf user@serverip:"/home/user/Fall 2008/" .

This will save report.pfg into your home directory. Notice the "."

More Information:

http://kb.iu.edu/data/agye.html

http://x.cygwin.com/

https://help.ubuntu.com/community/SSHHowto

Good Luck.

Conky: Display Last Pidgin Message

Recently, I removed the gnome-panels, added awn, and had a conky bar at the top. However, I missed having a system notification of when I would receive a message via Pidgin. So I browsed the pidgin wiki and create somewhat of a hack to display the last IM that received from Pidgin. This method is probably not the best way however I had some diffuculty.

The DBus method that listens for the received messages was chocking conky and not allowing the conky script to load correctly. So I had to create two files. getim.py would run at startup, listen for a new message and then write that message to a data file. lastim.py would be executed within conky and check the data file for the new message. I know its not real efficient and redundant but it just works. If you have any brilliant ideas please let me know.

Here is the getim.py file:

#!/usr/bin/python

# ----- GETIM.PY // LISTEN FOR AN RECEIVED MESSAGE ------------#
################################################################
# MOST OF THIS SCRIPT  WAS TAKEN FROM THE PIDGIN DEVELOPER WIKI#
# PLEASE VISIT http://developer.pidgin.im/ FOR MORE INFORMATION#
################################################################

def conky_im(account, sender, message, conversation, flags):
reg = '<(.|\n)+?>'                  # REGEX FOR HTML TAGS
message = re.sub(reg,'',message)    # REMOVE HTML TAGS
sender = sender.split("@")[0]       # GET GCHAT NAME
message = message[0:24]             # LIMIT TO 25 CHARS
file = ' '                          # LOCATION OF DATA FILE
fim = open(file,"w")
IM = sender + " said: " + message
fim.write(IM)
fim.close()

import dbus, gobject, re
from dbus.mainloop.glib import DBusGMainLoop
dbus.mainloop.glib.DBusGMainLoop(set_as_default=True)
bus = dbus.SessionBus()

bus.add_signal_receiver(conky_im,
                dbus_interface="im.pidgin.purple.PurpleInterface",
                signal_name="ReceivedImMsg")

loop = gobject.MainLoop()
loop.run()

Copy and paste the following and save as lastim.py:

#!/usr/bin/python

# SHOW LAST IM
f=" "                  # REPLACE WITH YOUR DATA FILE. ie.CONKYIM.DAT
fim = open(f,'r')
im = fim.read()
print im
fim.close

Finally, add this to your .conkyrc script

${execi 1 python ~/scripts/lastim.py}

Any questions/comments let me know. Here is a screen shot of what my conky looks like:
